1612906-1
Product Type Features
-
Connector System : Wire-to-Board, Wire-to-Device
-
Primary Locking Feature : Integrated in Housing
Configuration Features
-
Number of Positions : 24
-
Number of Rows : 2
-
Operating Voltage (VDC): 12
-
Nominal Voltage Architecture (V): 12
Body Features
-
Primary Product Color : Gray
Contact Features
-
Contact Type : Receptacle
-
Contact Size : .63mm
-
Mating Tab Width : .64 mm [ .025 in ]
-
Housing Material : PBT
-
Centerline (Pitch) : 2.2 mm [ .087 in ]
-
Operating Temperature Range : -30 – 105 °C [ -22 – 221 °F ]
Industry Standards
-
UL Flammability Rating : UL 94HB
