350779-1
Short Description:
Product Type Features
-
Rectangular Power Connector Type : Housing
-
Connector & Housing Type : Receptacle
-
Connector System : Wire-to-Panel, Wire-to-Wire
-
Sealable : No
-
Connector & Contact Terminates To : Wire & Cable
Configuration Features
-
Number of Positions : 2
-
Number of Power Positions : 0
-
Number of Signal Positions : 0
-
Number of Rows : 1
Electrical Characteristics
-
Operating Voltage (VAC): 600
Contact Features
-
Contact Retention Within Housing : Without
-
Contact Type : Pin
-
Multiple Contact Types : Without
-
Contact Layout : Inline
Termination Features
-
Termination Method to Wire & Cable : Crimp
Mechanical Attachment
-
Panel Mount Feature Type : Patch & Tabs
-
Panel Mount Feature : With
-
Connector Mounting Type : Panel Mount
Housing Features
-
Centerline (Pitch) : 6.35 mm [ .25 in ]
-
Housing Color : Natural
-
Housing Material : Nylon
Dimensions
-
Panel Thickness : .76 – 2.29 mm [ .76 – 2.29 in ]
Usage Conditions
-
Operating Temperature Range : -55 – 105 °C [ -67 – 221 °F ]
Operation/Application
-
Circuit Application : Power & Signal
-
Assembly Integration Feature : Without
Industry Standards
-
UL Flammability Rating : UL 94V-0
-
Glow Wire Rating : Standard Part —— Glow Wire750
