172167-1

Short Description:


Product Detail

Product Tags

Product Type Features

  • Rectangular Power Connector Type : Housing

  • Connector System : Wire-to-Panel, Wire-to-Wire

Configuration Features

  • Number of Positions : 4

  • Number of Rows : 2

Electrical Characteristics

  • Operating Voltage (VAC): 600

  • Operating Voltage (VDC): 600

Contact Features

  • Contact Type : Pin

Mechanical Attachment

  • Panel Mount Feature Type : Mounting Ears

  • Panel Mount Feature : With

  • Connector Mounting Type : Panel Mount

Housing Features

  • Centerline (Pitch) : 4.2 mm [ .165 in ]

  • Housing Color : Natural

  • Housing Material : Nylon 66

Usage Conditions

  • Operating Temperature Range : -20 – 105 °C [ -4 – 221 °F ]

  • UL Flammability Rating : UL 94V-0

  • Glow Wire Rating : Standard Part – Not Glow Wire
