180916
Short Description:
Product Type Features
-
Connector & Housing Type : Tab Housing
Configuration Features
-
Number of Positions : 1
Body Features
-
Primary Product Color : Natural
Contact Features
-
Terminal Type : Tab
-
Terminal Orientation : Straight
-
Contact Mating Retention : With
Mechanical Attachment
-
Mating Retention Type : Latch
-
Mating Alignment : With
-
Connector Mounting Type : Cable Mount (Free-Hanging)
Housing Features
-
Housing Material : Polyamide
Dimensions
-
Product Length : 31.1 mm [ 1.22 in ]
Usage Conditions
-
Operating Temperature Range : -40 – 105 °C [ -40 – 221 °F ]
Industry Standards
-
UL Flammability Rating : UL 94V-2
